Description
*** IMPORTANT NOTICE ***
THE VEHICLE NEEDS TO BE CHECKED THAT THE STARTER MAIN CABLE
RUNS DIRECT FROM THE BATTERY TO THE STARTER AND NOT VIA THE
ALTERNATOR. FAILURE TO SO THIS WILL RESULT IN THE STARTER
THE STARTER SOLENOID BURNING OUT AS WELL WHICH IS NOT
COVERED BY WARRANTY. GENUINE HOLDEN REPLACEMENT
HARNESS P/N: 95389088
BEFORE FITTING THIS STARTER, THE VEHICLE NEEDS TO BE CHECKED THAT THE STARTER MAIN CABLE RUNS DIRECT FROM BATTERY TO THE STARTER NOT VIA THE ALTERNATOR. FAILURE TO DO THIS WILL CAUSE THE NEW STARTER SOLENOID TO BURN OUT AS WELL AND IS NOT COVERED BY WARRANTY HOLDEN REPLACEMENT HARNESS P/N: 95389088 AND THE TORQUE SETTING FOR THE B+ NUT IS 10Nm
| Specifications | |
| Voltage | 12V |
| Kilowatt | 2.2kW |
| Number of Teeth | 9T |
| Pinion Diameter | 29mm |
| Rotation | CW |
| Pinion at Rest | 22mm |
| Flange Diameter | 82mm |
| Mount Hole Center to Center | 113 x 105 x 36mm |
| Mount Hole Diameter | 10mm |
| Overall Length | 238mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) | 4.5kg |
